This machine is in stock!
Technical specifications
| Condition | Used |
|---|---|
| Max swing over bed (mm) | 3050 |
| Centre distance (mm) | 21200 |
| Year of Manufacture | 1958/2008 |
| Control | SIEMENS 840D |
| Max swing over cross slide (mm) | 2500 |
| R.P.M. | 0.236 - 60 |
| kW | 200 |
| Volts (V) | 400 |
| Cycles (Hz) | 50 |
| 4-Jaw chuck ø (mm) | 3000 - 2000 |
| Steady rest ø (mm) | 750 - 1200 |
Included parts & extra info
4-Jaw face plate Ø 3000mm
4-Jaw face plate Ø 2000mm thickness 330mm
Work rest roller type Ø 680mm
2 x Steady rest roller type Ø 750mm
2 x Steady rest roller type Ø 1200mm
Follow rest Ø 2000mm
Boring bar 450 x 10300mm
Boring bar 650 x 11100mm
Rollenbock
Rollenbock with adaptor
